| Growing Orientation | Along Y-axis | Maximum Length(5x5mm) | 25mm |
| Length Tolerance | +0.5 / -0.1 | Width and Height Tolerance | +/-0.1 |
| Parallelism | < 30″ | Perpendicularity | < 15′ |
| Surface Quality | 20/10 | Coating | AR-coated |
Basic Properties:
| Crystal structure | Orthorhombic | Cell Parameters | a = 12.96 Å; b =10.56 Å; c =6.49 Å |
| Mohs hardness | About 5 | Density | 3.6 g/cm3 |
| Melting Point | About 1000˚C | Thermal Expansion Coefficients (/K) | αx=1.01x10-5 , αy =1.37x10-5 , αz =-4..17x10-6 |
| Sellmeier Equations (λ in μm) |
nx2=2.15559+0.93307[1-(0.20994/λ)2]-0.01452λ2 ny2=2.38494+0.73603[1-(0.23891/λ)2]-0.01583λ2 nz2=2.27723+1.11030[1-(0.23454/λ)2]-0.01995λ2 |
Thermo-optical Coefficients (dλ/dT) | -0.029nm / °C |
| Electro-optic Constants (Y-cut) (X-cut) |
r33=38.5 pm/V r33=35 pm/V,r23=12.5pm/V, r13=10.6 pm/V |
Electrical Resistivity | About 1011-1012ohm·cm |
| Static Half Wave Voltage at 1064nm |
4x4x20mm:1.600V 6x6x20mm:2.400V 9x9x20mm: 3.600 V |
Extinction Ratio | >20dB@633nm |
